Sale!
Dorex GX1 SERIES Heavy Duty Satin Chrome Passage Lever
Original price was: $173.10.$129.99Current price is: $129.99.
GX1 SERIES GRADE 1
DOREX GX1 door locks (GX1C, GX1L, GX1S) are designed for high traffic areas requiring heavy-duty locks with enhanced security features. Ideal for commercial areas such as office buildings, universities, industrial and institutional facilities.
- Conforms to ANSI/BHMA A156.2, series 4000, Grade 1
- cULus listed, 3 hr fire rating
- ANSI/UL 10C Positive Pressure Rated
- Meets ADA requirements
- 10 Year limited warranty
- For doors 13⁄8 to 2″ (35 to 51 mm) thick
- Non-handed
- 23⁄4″ (70 mm) backset
- 23⁄8″, 33⁄4″ and 5″ (60 mm, 95 mm and 127 mm) backsets available
- Stainless steel latch with 1⁄2″ (12.7 mm) throw
- Deadlatch with 3⁄4″ (19 mm) throw available
- Fixed security posts
- Lever clutch release for damage prevention
- 39⁄16″ (90 mm) rose diameter
- Concealed mounting plate and screws
- ASA strike
- Keyed functions include 6-pin cylinder, Schlage “C” profile with 2 keys
- Small format interchangeable core (SFIC) model available (BEST-F® and CX5® cores sold separately)
Full keying services available. Other common and high security keyways available.
| Weight | 2.26796 kg |
|---|---|
| Dimensions | 20.32 × 17.78 × 7.62 cm |
