Sale!
Dorex 9500 TL70 Heavy Duty Satin Chrome Classroom Function Lever Trim
Original price was: $170.00.$125.99Current price is: $125.99.
9500 SERIES Classroom Function Lever Trim
- For 9500 Series exit devices
- cULus listed, 3 hr fire rating
- ANSI/UL 10C Positive Pressure Rated
- 5 Year limited warranty
- For doors 13⁄8– 13⁄4″ (35 – 44.5 mm) thick
- Non-handed
- 23⁄4″ (70 mm) backset
- 23⁄8″, 33⁄4″, and 5″ (60 mm, 95 mm and 127 mm) backsets available
- Stainless steel latch with 1⁄2″ (12.7 mm) throw
- 3″ (76 mm) rose diameter
- Concealed mounting plate and screws
- ASA strike
- Keyed functions include 6-pin cylinder, Schlage “C” keyway with 2 keys
| Weight | 2.26796 kg |
|---|---|
| Dimensions | 20.32 × 17.78 × 7.62 cm |
